The P50 is a puck-style, in-hull, widebeam 600W CHIRP transducer for bass and walleye boats. It is designed to transmit through fiberglass and aluminum hulls. This unit operates in the Low (47-52 kHz) and High (190-210 kHz) bands. It also functions as a conventional transducer at 50/200 kHz.
The in-hull design eliminates the risk of damage from external hazards such as sandbars or rocks.
Specifications
| Feature | Specification |
|---|---|
| Low Frequency Band | 47-52 kHz |
| High Frequency Band | 190-210 kHz |
| Other Available Frequencies | 50/200 kHz |
| Housing | In-hull |
| Power Rating | 600W |
| Beam Widths | 11° in High band; 45° in Low band |
| Temperature Sensor | None |
| Transducer Cable | 10 meters (32.8 feet) with bare wire connection |
| Hull Material | Solid fiberglass or aluminum |
| Overall Height | 1.6" (4 cm) |
| Overall Width | 2.68" (6.8 cm) |
| Recommended Boat Size | Bass and walleye boats |
Available Models
| Version Name | Characteristics |
|---|---|
| P50C-LWH | Widebeam dual-Band (Low/High) CHIRP transducer |
