The Furuno DFF1-UHD is a dual-band network sounder for use with Furuno NavNet TZtouch and NavNet 3D displays.
It is designed for Airmar dual-band Low/High CHIRP transducers.
The DFF1-UHD transducer connection is a bare-wire connection to an internal junction block behind a removable panel. Connection to the displays is through a Furuno Ethernet cable.
Specifications
| Feature | Specification |
|---|---|
| Frequency Bands | Low : 30-70 kHz; High : 175-225 kHz |
| Transducer Connector | Bare wire |
| Transducer Compatibility | Airmar dual-band Low/High CHIRP transducers |
| Display Connection | Furuno Ethernet Cable |
| Compatible Displays | Furuno NavNet TZtouch, NavNet 3D |
| Dimensions | 380mm (15.0") x 320mm (12.6") x 120mm (4.7") |
| Weight | 3.5 kg (7.7 lbs) |
| Power Supply | 12V DC or 24V DC |
