The M175 is an in-hull 1kW CHIRP transducer that chirps in the Medium (85-135 kHz) band. It is designed to transmit through solid fiberglass hulls.
Specifications
| Feature | Specification |
|---|---|
| Medium Frequency Band | 85-135 kHz |
| Housing | In-hull |
| Power Rating | 1kW |
| Beam Widths | 16-24° in Medium band |
| Temperature Sensor | None |
| Transducer Cable | 10 meters (32.8 feet) with bare wire connection |
| Hull Material | Solid fiberglass |
| Overall Height | See diagram |
| Overall Width | See diagram |
Available Models
| Version Name | Characteristics |
|---|---|
| M175C-M | In-Hull single-band CHIRP transducer |
