The Raymarine CP570 is a very high-performance dual-band CHIRP network sounder. It is for use with either Airmar dual-band transducers or pairs of single-band transducers.
Connection to the display is by Raynet.
Specifications
| Feature | Specification |
|---|---|
| Part Number | E70298 |
| Frequency Bands | 25-255 kHz |
| Transducer Connector | Raymarine connector |
| Transducer Compatibility | Airmar dual-band Low/Medium or Low/High CHIRP transducers up to 4kW, or pairs of Airmar single-band Low, Medium or High CHIRP transducers. |
| Display Connection | Raynet |
| Compatible Displays | aSeries, cSeries, eSeries, eS Series, gS Series |
| Dimensions | 352mm (13.9") x 328mm (12.9") x 110mm (4.3") |
| Weight | 6.35 kg (14.0 lbs) |
| Power Supply | 12V DC or 24V DC |
| Other non-CHIRP Functionality | N/A |
