The Raymarine CP450C is a dual-band CHIRP network sounder for use with Airmar Low/Medium or Low/High CHIRP transducers up to 1kW.
Connection to the display is by Raynet.
Specifications
| Feature | Specification |
|---|---|
| Part Number | E102143 |
| Frequency Bands | 25-250 kHz |
| Transducer Connector | Raymarine connector |
| Transducer Compatibility | Airmar dual-band Low/Medium or Low/High CHIRP transducers up to 1kw |
| Display Connection | Raynet |
| Compatible Displays | cSeries, eSeries |
| Dimensions | 299mm (11.77") x 205mm (8.07") x 88mm (3.45") |
| Weight | 1.539 kg (3.39 lbs) |
| Power Supply | 12V DC or 24V DC |
| Other non-CHIRP Functionality | Supports conventional 50/200 kHz trasnducers |
