The Simrad BSM-3 is a high-performance dual-band CHIRP network sounder for NSS Sport, NSE Expert and NSO Offshore displays.
It is compatible with Airmar dual-band CHIRP transducers in the Low/High bands only. The Medium band is not supported.
Connection to the display is by a Simrad Ethernet cable.
This device can also be used with select Lowrance HDS-Series displays
Specifications
| Feature | Specification |
|---|---|
| Part Number | 000-11742-001 |
| Frequency Bands | Low 25-45 kHz or 40-60 kHz; Medium not supported; High 130-210 kHz |
| Transducer Connector | Bare wire connection to internal junction strip |
| Transducer Compatibility | For use with any Airmar 1-3 kW dual-band CHIRP transducer in the Low/High band. |
| Display Connection | Simrad Ethernet |
| Compatible Displays | Simrad NSS Sport, NSE Expert and NSO Offshore |
| Dimensions | 340mm (13.4") x 289mm (11.4") x 100mm (3.9") |
| Weight | 4.8 kg (10.6 lbs) |
| Power Supply | 12V DC or 24V DC |
| Other non-CHIRP Functionality | Supports conventional transducers at 28 kHz, 38 kHz, 50 kHz and 200 kHz |
